RZ1350RK
RZ1350RK
| The main parameters | Host weight | 4250G |
| System measurement accuracy | Plane: 5cm, @200m Elevation: 8cm, @200m | |
| The maximum scanning distance of the instrument | 1350M | |
| Maximum pulse emission frequency | 820KHz | |
| Maximum scan angle | 330° | |
| Maximum number of echoes | Endless |
| Combined Navigation Parameters | INS type | Fiber optic inertial navigation |
| Positioning System Mode | L1、L2、B1、B2、G1、G2 | |
| IMU update frequency | 200Hz | |
| Heading Accuracy (Postprocessing) | ≤0.017° (RMS，GNSS not lost lock) | |
| Roll Accuracy/Pitch Accuracy (Post-processing) | 从0.005° (RMS，GNSS not lost lock |
| Electrical parameters | Operating voltage | DC12~28V |
| Power | 84W | |
| Mount interface | OSKD |
| Zeiss camera (optional) | Camera weight | 400G |
| Camera pixels | 42 million | |
| Camera resolution | 7952*5304 | |
| Focal length | 21mm |
